Sample substrate
|
Thermoplastic sheet film
|
|
Sample size
|
300(W)~400(L)mm (min150)
|
|
Sample thickness
|
50 ` 1,000 m
|
|
Stretching stroke
|
MAX 450mm
|
|
Stretching speed
|
MAX 15mm/sec
|
|
Oven temperature
|
MAX 250
(250
option)
|
|
Heating
|
Heated air blowing circulation type
|
|
Blowing air speed
|
3 ` 5 m/sec
|
|
Heated air contact area material
|
SUS304
|
|
Nozzle-sample distance
|
100mm
|
|
Electric heater
|
12kW
|
|
Circulating fan motor
|
1.5kW
|
|
Stretching drive motor
|
AC servo motor 50W
|
|
Operation
|
Touch panel (color)
|
|
Clip
|
KMD-special SUS304₯ALBC
|
@ |
